830nm
1-30mW Diode Laser
|
|
|
Specifications |
Model
|
SL-830nm-XXXT
|
Output
Power @ 25 ¡æ
|
1-30mW((5mW,10mW,20mW
and 30mW can be selected))
|
Wavelength
|
830nm¡À10nm
|
Operation
Mode
|
CW
|
Transverse Mode |
Near TEM00 |
Power stability
(rms, over 4 hours)
|
<5% |
Warm-up time
(minutes)
|
<10
|
Beam
Divergence (1/e2, Full Angle)
|
< 2.0mrad
|
Beam diameter
at the aperture (mm)
|
<3.0
|
Operating temperature (¡æ)
|
10¡«35
|
Input Voltage
(VAC)
|
80-260
|
|
TTL Modulation or Analog
Modulation
|
Expected Operating Lifetime
|
|
Warranty time |
one year
|
|
|
