Low Noise 635nm Red Laser
|
|
Specifications
|
|
Model |
SL-635nm-LN-XXXT
|
|
Wavelength |
635nm(red) |
|
Output power
|
100-500mw
|
|
Beam Mode
|
Low order
transverse mode,TE00 |
|
Power Stability |
<5% |
|
Warm-up time (minuter) |
<15 |
|
M2 Factor |
<20 |
|
Spectral linewidth (nm) |
<2 |
|
Polarization ratio |
>50:1 |
|
Output Noise (r.m.s, 10Hz - 20MHz) |
<1% |
|
Operating Temperature |
10¡æ¡«30¡æ |
|
Point Stability |
<0.05 |
|
Beam Diameter
|
< 5mm
|
|
Beam Divergence
|
< 5mrad
|
|
Operating Mode
|
cw/pulse
|
|
Expected operating
lifetime
|
> 5000 hours
|
|
Laser Size |
120¡Á60¡Á52
|
|
Power
|
80-260VAC |
|
Modulation |
TTL or Analog |
|
