650nm Dot series laser diode modules

SL-650nm-LM-001(8x17mm)

SL-650nm-LM-003(8.5x26mm)

SL-650nm-LM-005(10x20mm)

SL-650nm-LM-007(8x17mm)

SL-650nm-LM-011(9x17.5mm)

SL-650nm-LM-013(9x28mm)

SL-650nm-LM-015(10x35mm)

SL-650nm-LM-002(8x23mm)

SL-650nm-LM-004(6x11mm)

SL-650nm-LM-006(8x18.5mm)

SL-650nm-LM-010(10x20mm)

SL-650nm-LM-012(11.5x30mm)

SL-650nm-LM-014(14x80mm)

SL-650nm-LM-016(12x23mm)

mounting brackets 1

mounting brackets 2

Specifications

　Model

Wavelength
( nm )

Output power
( mw )

Divergence
( mrad )

Beam size

Lens

SL-D--650nm-5mw

650nm

< 2.5

< 0.1

<φ4mm (@5m)

Glass

650nm

< 3.5

<0.6

<φ1mm (@1m)

Glass

650nm

< 4

<0.1

<φ4mm (@5m)

Glass

650nm

< 5

<0.1

<φ1mm (@1m)

Glass

SL-D--650nm-10mw

650nm

< 6

<0.6

<φ4mm (@5m)

Glass

650nm

< 8

<0.1

<3x6mm (@5m)

Glass

650nm

<10

<0.1

3x6mm (@10m)

Glass

SL-D--650nm-20mw

650nm

< 15

< 0.2

3x6mm (@5m)

Glass

650nm

< 18

< 0.1

3x6mm (@10m)

Glass

SL-D--650nm-30mw

650nm

< 25

< 0.1

3x6mm (@10m)

Glass

650nm

< 27

< 0.1

3x6mm (@10m)

Glass

SL-D--650nm-40mw

650nm

< 32

< 0.1

3x6mm (@10m)

Glass

650nm

< 35

< 0.1

3x6mm (@10m)

Glass

SL-D--650nm-50mw

650nm

< 40

< 0.2

3x6mm (@10m)

Glass

650nm

< 45

< 0.1

5x10mm (@20m)

Glass

SL-D--650nm-50mw

650nm

< 50

< 0.1

3x6mm (@10m)

Glass

650nm

< 55

< 0.1

3x6mm (@10m)

Glass

SL-D--650nm-70mw

650nm

< 65

< 0.1

5x10mm (@20m)

Glass

Dimensions(mm): can be choosed as blew

￠6.5x11, ￠7x14, ￠8x20, ￠8x25, ￠8x30,￠9x21, ￠9x25, ￠10x32, ￠10x36, ￠10.5x30, ￠12x32,￠12x36, ￠13x35, ￠14x36.5,￠14x42, ￠16x50, ￠16x70, ￠18x60, ￠20x70, ￠22x80, ￠22x90.5, ￠26x70, ￠26x110
