635nm Red Laser 1-50mw Cross Line Module

Specifications

Model

SL-635nm-RLM-003(Cross Line)

Wavelength

635nm(red)

Output Power

Class IIIA P<5mW
Can design high power laser modules(such as 10mW，20 mW，50 mw etc.)

Beam Mode

Fixed focus, high quality glass focus lens, straight line light shape

Working Current

I<60mA

Trigger Voltage

DC=2.3V

Working Voltage

DC=4.5V

Expected Operating Lifetime

> 5000 hours

Laser Size

φ16×45mm

Line Width

<2.5mm at 10m, <3.5mm at 15m
