635nm Dot series laser diode modules

Specifications

　Model

Wavelength
( nm )

Output power
( mw )

Operating Current

Operating Voltage

Lens

SL-D--635nm-5mw

635nm

< 1

<40mA

Glass

635nm

< 3

<40mA

Glass

635nm

< 4

<45mA

Glass

635nm

< 5

<50mA

Glass

SL-D--635nm-10mw

635nm

< 6

<60mA

Glass

635nm

< 7

<70mA

Glass

635nm

< 10

<80mA

Glass

SL-D--635nm-20mw

635nm

< 15

<90mA

Glass

635nm

< 20

<100mA

Glass

SL-D--635nm-30mw

635nm

< 25

<120mA

Glass

635nm

< 30

<150mA

Glass

Dimensions(mm): can be choosed as blew

￠6.5x11, ￠7x14, ￠8x20, ￠8x25, ￠9x21, ￠9x25, ￠10x32, ￠10x36, ￠10.5x30, ￠12x32, ￠12x36, ￠13x35, ￠14x36,￠14x42, ￠16x50, ￠16x70, ￠18x60, ￠20x70, ￠22x80, ￠26x70, ￠26x110
